Axle-Spider Hub Series
Axle-Spider Hub Series Specification
|
Axle Type
|
Max Capacity
|
Track
(mm)
|
Brake
(mm)
|
CentreDistance
Of Spring Seat(mm) |
Axle Beam(mm)
|
Centre Distance
Of Brake Chamber(mm) |
Wheel Fixing
|
Recom
mended wheel
|
(kg) Axle Weight
|
Note
|
|||
|
Stud
|
D1P.C.D
(mm）
|
D2 Hole Diameter
|
Total Length
(mm)
|
||||||||||
|
HF-12
|
12
|
1870
|
420*220
|
≥970
|
150*150
|
306
|
ISO
|
335
|
/
|
2220
|
8.50V-24
|
460
|
Bearing(Inner)32218
Bearing(Outer)3318 |
|
HF-14
|
14
|
1870
|
420*220
|
≥970
|
150*150
|
236/286
|
ISO
|
335
|
/
|
2173/2223
|
8.50V-24
|
510
|
Bearing(Inner)32222 Bearing(Outer)32314 |
|
HF-16
|
16
|
1820/1870
|
420*220
|
≥970
|
150*150
|
236/286
|
ISO
|
335
|
/
|
2233/2283
|
8.50V-24
|
535/539
|
Bearing(Inner)32222
Bearing(Outer)32314 |
